Steamist SMP Series

SMP Series

Compatible with all Total Sense Spa Upgrades



SMP Series

Just want Steam

All you need to get is a suitably sized steamer (SMP) and the standard control (TSC250).

  • Best Warranty: Lifetime parts, Two years Labour (one year on control).
  • Waterproof temperature control mounts inside steam shower.
  • Matching steam head and 35' control cabe
  • American made to the highest quality standards.
  • A full range of sizes from 5 kw up to 30 kw
  • A wide variety of conmtropl and colours.
  • UL & CUL approved for Canada and USA
  • Compatible with all Total Sense Spa Upgrades

Total Sense Features

Upgrade to one of the TSC550 WiFi controls and then you can add any or all of the Total Sense "Spa" features; including:

  • ChromaSense mood light
  • AudioSense bluetooth music system
  • AromaSense built in scent dispenser
  • ShowerSense sleek, clutter-free shower system

Select a Type

Steamist is American made to the highest quality and comes with a exceptional warranty and reliable service support.
The SMP steam generator carries a Two-Year labour and Lifetime parts warranty.





Select a Tab Below for More Info

ES vs. SMP vs. TSG

Sizing Your Steam Generator

SMP Steam Installation Manuals

Steam Controls

ChromaSense

AromaSense

AudioSense

ShowerSense

                   es steam generator vs smp series vs. tsg steamist

Model No. KW Rating * Max. Cu.Ft. Range Model Dimensions L"xW"xH"
SMP 5 100 15 x 6 x 15.5
ES
SMP/TSG
7.5 250 15 x 6 x 15.5
ES
SMP/TSG
10 450 15" x 6" x 15.5"
ES
SMP/TSG
12 550 17.75 x 7.5 x 15.5"
ES
SMP/TSG
15 675 17.75 x 7.5 x 15.5"
ELITE
SMP/TSG
20 900 19 x 11.5" x 17"
ELITE
SMP/TSG
24 1100 19 x 11.5" x 17"
ELITE
SMP/TSG
15 675 19 x 11.5" x 17"

* Maximum cubic foot range is based on adjusted area after factoring in things like wall material height,etc.
Standard residential voltage for North America is 240 volt, single (1) phase.
208 volt, single (1) phase and 3 phase models also available.


Sizing Your Steam Generator

Steam sizing is more than just cubic area.  You must factor in things like wall finish (tile vs. stone), exterior walls and height to arrive at the correct "Adjusted Cubic Area".

To “size” the right generator, we start by asking for some basic information about the space you’ll be using for your steam shower.

Length x Width x Height (in feet) of the steam enclosure to determine cubic footage.
For optimum performance, ceiling height should not exceed 8'. The maximum recommended ceiling height is 10'.

a.  L x W x H = _______
"Adjusted Cubic Area" is determined by a number of factors.

b.  Wall material:
Tile: ceramic / porcelain / glass / glass block. Add 35% _______
Natural stone: Add 100% ______

c.  Number of Exterior walls:
one wall: add 10% _____
two walls add 20% _____

d. Height: no additional factor for 8' or less:
9' height: add 15%  _____
10' height: add 30% _____

Adjusted Cubic Area = a + b + c + d
(If there window or skylight, select next larger steamer)

Example 1: 5' x '5 x 8'. Porcelain tile, one exterior wall
5x5x8=200'. Tile +70', exterior wall +20' = 290' = SMP-7, 7.5 kW steamer

Example 1: 4' x '5 x 9'.
Marble 4x5x9=200'. Stone +200', 9' height +30' = 430' = SMP-10, 10 kW steamer

SMP Series Steam Generators

Model No. KW Rating Max. Cu.Ft. Range Volts/
Phase
Min. Wire Size Max. Fuse Size Model Dimensions L"xW"xH"
SMP-5 5 100 240/1 10 30 15 x 6 x 15.5
SMP-7 7.5 250 240/1 8 40 15 x 6 x 15.5
SMP-10 10 450 240/1 6 50 15" x 6" x 15.5"
SMP-12 12 550 240/1 4 60 17.75 x 7.5 x 15.5"
SMP-15 15 675 240/1 3 80 17.75 x 7.5 x 15.5"

** Wire/breaker size is recommendation only.
Consult your licensed electrician to confirm requirements.

Sizing Your Steam Generator
Steam sizing is more than just cubic area.  You must factor in things like wall finish (tile vs. stone), exterior walls and height to arrive at the correct "Adjusted Cubic Area". For optimum performance, ceiling height should not exceed 8'. The maximum recommended ceiling height is 10'.

Standard residential voltage for North America is 240 volt, single (1) phase.
208 volt, single (1) phase and 3 phase models also available.

SMP Steam Installation Manual

ES Steamer (Elite)

ec150  Series es steam control

ES Steam control:   EC-150  Series Standard Control

On/Off bottom, temperature control
(Size: 2-3/4" x 2-3/4")





SMP and TSG Steam Generators:

smp and tsg steam gnerator tsc250 series control

TSC250 Series Control

Programmable for two user profiles with individual temperature/duration preferences.
Will not operate Total Sense Spa Options.
Many color options

(Size: 3-3/4" x 3-3/4")



smp and tsg steam gnerator tsc550 series control

TSC550 Series Control

TSC 550 is a touch-screen, WiFi control.
Available in modern and transitional styles.
Many color options.
TSC 550 required if you plan to add any of the TSC Spa Options (ChromaSense, AromaSense, AudioSense or ShowerSense).
TSC550 can be ordered without Spa options if you simply like the modern look better.
(Size: 3-5/8" x 5-3/4")

Chromatherapy at Home

Let color enrich your steam experience

ChromaSense can turn you on to a spectrum of six steam shower lighting effects to bring about positive physical or psychological change. Compatible with the 550 Digital Steam Control.
ChromaSense Spa Option Control Module: Product Code TSCH.
Supplied with Light Fixture with Polished Chrome Trim Ring. Designer Finish Trim Rings also available.

Six color effects

With one shower light fixture, ChromaSense gives you the choice of selecting white light or six color effects in the steam shower.

Soulful

Bliss

Relax

Creative

Energize

Harmony



AROMASENSE:  HEAL WITH AROMATHERAPYAromasense aromatherapy for steam showers

Add scents of well-being to your steam shower

For centuries, aromatherapy has demonstrated remarkable therapeutic powers, from relaxing body and spirit to soothing respiration to sparking creativity. And only Steamist’s AromaSense adds 100% undiluted essential oils to the steam shower, ensuring your pure pleasure. Compatible with the 550 or 450 Digital Steam Control.
AromaSense Spa Option Control Module: Product Code TSA



Pure essential oilsessential oils for steambaths

Only Steamist’s AromaSense has a precision pump system that stores two different, easily replaceable essential oil canisters. allowing you to make your “aroma steam” selection without ever leaving your steam room. And only AromaSense uses pure undiluted oils, using just 1/4 of a drop at a time, so each canister will last for months. Five essential oils are available in 100 ml canisters (sold separately).
Two essential oil canisters should be purchased for installation with the AromaSense module.

AUDIOSENSE: EXPERIENCE SOUND AND STEAMaudiosense steambaths speakers

With AudioSense you can enjoy your favorite music in the steam shower from your computer, smartphone, iPod tablet or any other Bluetooth-enabled music player. Compatible with the 550 or 450 Digital Control. 550 Digital Controls links directly to Pandora®, Spotify® or iHeart® music streaming services. Speakers sold separately.

Speaker Options

audiosense steambaths speakers

  • Two "Invisible" Speakers
  • Mount out of sight and transmit sound through the wall.
  • 3" diameter. Product Code TSS-IN
  • Two "Classic" Exposed Speakers
  • Surface mount.
  • 5.25: diameter, 8" outside diameter. Product Code TSS-CL

ShowerSense: showeersense steam shower

The Cleaner Choice

Cluttered Conventional Shower

A standard showerhead, handheld shower and body sprays require multiple controls and a cluttered, crowded enclosure.

Uncluttered ShowerSense System

With ShowerSense, one control covers all steam and shower functions, for a beautiful shower retreat without multiple shower controls.

Our Digital Shower System allows you to enjoy the benefits of ShowerSense without installing a steam generator and steamhead.

Ultimate Shower Options

showeersense steam shower generatorShowerSense lets you enjoy the steam experience, plus your choice of three luxury shower options. The 550 Digital Control lets you select either of two different shower temperatures, and gives you total touchscreen command over all steam and shower functions, without the clutter of multiple shower controls. The ShowerSense Valve is easy to install in any position behind the wall, and is both temperature compensating and pressure-balanced to optimize user comfort.

ShowerSense Spa Option Valve: Product Code TSSH
